Quick Details

  • Use: Truck Trailer
  • Type: Semi-Trailer
  • Material: Steel
  • Certification: CCC,ISO,SGS,BV
  • Size: 13000X3000X1700
  • OEM No.: Liangshan Juyuan Special Vehicle Manufacturing Co.,Ltd
  • Max Payload: 40 tons
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: AOTONG
  • Model Number: LAT9539TDP
  • Low Bed Deck Dimension: 13000X3000X1750mm
  • Axle: 2 axle low bed trailer
  • Tyres: 8, 11.00R20-16PR or 12R22.5-16PR
  • Suspension System: Mechanical/Air Suspension
  • Brake System: Dual Line pneumatic brake with six air chambers
  • Kingpin: 2" or 3.5" interchangable
  • Landing Gear: JOST 28Tons heavy duty
  • A pair of Ladders: Mechanical or Hydraulic
  • Color: As Customers' need

Packaging & Delivery

Packaging Details N/M
Delivery Time 15



Low Bed Semi Trailer

2 axles 40 tons atv log loader, lowboy semi trailer, low loader semi trailer for sale

Basic Specifications
Overall Dimentions optional; 13000*2500/3000*1680mm
Related Load 60 Tons
Tare Weight 9 Tons
Overhang 450mm
Running Gear
Axle 13T*3 pieces ; FUWA or BPW
Tire size and brand optional; 12R22.5; 11.00R20
Suspension Air suspension or machanical suspension with 10 leaf springs
Braking System dual line pneumatic braking system with brake chamber and WABCO valve,ABS
Under Frame
Main Beam height 500mm; Q345 material. thickness depends on the loading capacity
Cross Beam 80*40 square tube
Side Beam 16# or 25# channel steel
Loading Deck 4mm or 5mm diamond plate
Rear Ladders machanical ladders or hydraulic folding ladders
King pin JOST 2' or 3.5' interchangeable
Landing Gear 28T two-speed manual operating
Electrical System
Standard 1.Voltage: 24v  2. Receptacle: 7 ways (7 wire harness)
Lights and Reflectors standard reflectors and LED lights (rear light, side light, turning light, number plate light, fog light)
Painting and Accessories
Painting three coats painting; RAV color optional
Tool Box size depends; with standard tools
Spare Tire Carrier 1 or 2 pieces
Fender and Hook standard fender and chain hooks



Packaging & Shipping

1. We will spary wax for the trailer before shipment against saltwater corrosion.

2. Regarding to the shipping method, you could choose which one is better for you, by container vessel, Ro-Ro vessel or by bulk vessel.

3. We provide lowest shipping freight based on the long-term cooperation relationship with ship agency.



FAQ



 1. Q: What are the applications of low bed semi trailer?

 This series low bed semi trailer applicable for the transportations of the mechanical equipment, excavators , bulldozer, large objects, highway construction equipment, large tanks, power plant equipment or machine, and all sorts of steel products.



2. Q: Are you a factory or trading company?
A: We are a factory. We manufacture all kinds of Semi Trailers.


3. Q: Where is your factory located? How can I visit there?

A: Our factory is located in Industry Park, Liangshan Town, Jining City, Shandong province,China.

     All our clients, from home or abroad, are warmly welcome to visit us!



B: We can pick up our dear customers at Jinan airport.

4. Q: What is the material of your products?
A: The materials are Carbon Steel, Stainless Steel, ALuminum Alloy: Q235,Q345,Q690; SS314, SS316; AL5454, AL5083.  Different material for different semi trailers.

5. Q: How can I get some samples?


A: We can accept small order, MOQ 1 set, at the first cooperation and make production after you paying for us.

B: Delivery time is 18 days. 30% deposit before production; 70% balance should be paid before delivery.

You just tell me the port name and our forwarder will ship the semi trailer to your port.



6. Q: How does your factory do regarding quality control?

A:  "Quality is priority.''Our inspector QC will check semi trailer  in every procedure and modify the parts once they find any problems from them.

B: For our salesman will also check semi trailer and take photos for every procedure for our client to confirm.



7. Q: What are your advantages doing trailer business?



  1. Creative design for your own special transportation program.
  2. High tensile steel provides the strongest performance of semi trailer.
  3. Automatic submerged arc welding and straightening machines make best main beam.
  4. One coat blasting plus two coats polyester painting.
  5. Standard and Brands of semi trailer parts can be chosen according to different requests.
  6. Necessary accessories offered.

8. Q: What will be the process of doing business with you?



Our Services

1. Professional design model of lowboy trailer for customers' special requirements.

2. Strict Quality Control for the lowboy trailer.

3. Longer guarantee terms for the lowboy trailer in whole Chinese market.



THE MAIN COMPONENTS OF THE WARRANTY PERIOD (SEE TABLE):

ITEM NAME

WARRANTY

ITEM NAME

WARRANTY

MAIN FRAME

 FRAME

12 MONTHS

RUNNING GEAR

AXLE

12 MONTHS

SUSPENSION

12 MONTHS

AXLE BEARING

12 MONTHS

KING PIN

12 MONTHS

WHEEL HUB

6 MONTHS

BALANCE ARM

12 MONTHS

TIRE

6 MONTHS

ITEM NAME

WARRANTY

ITEM NAME

WARRANTY

BRAKING DEVICE

BRAKE DRUM

6 MONTHS

SUPPORT DEVICE

LANDING GEAR

6 MONTHS

BRKE CHAMBER

6 MONTHS

SPARE WHEEL CARRIER

6 MONTHS

AIR RESERVOIR

12 MONTHS

ITEM NAME

WARRANTY

OTHERS

LEAF SPRING

3 MONTHS

BRAKE CHAMBER DIAPHRAGM

3 MONTHS

EMERGENCY RELAY VALVE

3 MONTHS

BRAKE SHOE

3 MONTHS

RELAY VALVE

3 MONTHS
