Quick Details

  • Use: Truck Trailer
  • Type: Semi-Trailer
  • Material: Steel
  • Certification: ISO CCC
  • Size: 13000*3000*1290(mm)
  • OEM No.: GRYI8UO9
  • Max Payload: 80T
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: AOTONG
  • Model Number: LAT0001TDPA
  • color: as client's need
  • length: 12-13meters
  • axles brand: FUWA or BPW
  • suspension: air suspension or rigid suspension
  • load capacity: 60-100tons
  • trailer name: detach neck trailer
  • hydraulic: 2 pcs

Packaging & Delivery

Packaging Details in nuld.
Delivery Time Shipped in 30 days after payment

DTA 3 /4 /6 Axle Hydraulic Detach Neck Crane Hauling Lowboy,lowbed semi trailer factory cell :8615650187200

HOT products 2015 excavator transporting 3 axles 60ton low bed trailer with ladder

Your certern----

lowbed /low bed /lowboy /low boy /low loader/ for excavator transport,for road roller and digger optional

10ton 20ton,25ton,30ton,35ton,40ton,45ton,50ton,55ton,60ton,65ton,70ton,75ton,80ton,85ton,90ton,100ton,110ton,120ton,150ton,160ton,180ton,200ton,250ton,300ton,500ton,800ton,1000ton,1500ton  all the capacity is depends on the customer requirements.

gooseneck concave beam or straight beam optional

  FUWA or BPW or JINSHENG axles optional

  Germany or Amercian optional

  rigid suspension or air suspension optional

  Yellow color red color bule or other color optional



1-lowbed series
                           WELCOME TO JUYUAN

Product Information

Product

Low bed semi trailer



Brand Name

Aotong Brand

Model Number

LAT****TDP

Announcement (batch)

229

Place of Origin

Shandong province, China

Color

Any color will be available

Manufacturer

Liangshan Juyuan special vehicle manufacturing Co., Ltd

Product Specifications

Parameter

Outside Dimensions (L*W*H)

L:12000-20000     W:2400-4000    H:900-1500

Rated Load

30ton-500ton

Tare Weight

More than 9000kgs

Wheel   Base

8480+1310 (mm)

Running Gear

Tires

specification

12R22.5 ,11.00R20 or depends on customer

No. of tires

8,12,16 or more than 20

Spare tire carriers

2 or 1 including a riser.

Axles



Brand :

FUWA (BPW German optional)

No. of axles:

2,3 4 or more than 5

Axle-load

13000kgs

      Wheel rim

8units of 7.50-20 rim or 8.00

Suspension

Rigid suspension and air suspension

Pieces of leaf-spring

10/10/10

Brakes

brand

TKL brand

Brake chamber

4 double chamber

System

Dual line braking system /ABS

Under Frame

Departure Angle

14

Front/Rear   Overhang

1670mm

Main Beam

material

I beam ,Q345B , automatic submerged arc welded

specification

Height is 500mm,upper plate is 20mm,lower plate

 is 20mm,middle is 12mm

Cross Beam material

Q235B

Side beam

16# channel steel

Plate form

Steel Sheet 5mm thickness or diamond plate(Also can choose

other thickness ,such as 2mm,2.5mm,3mm,4mm,5mm,6mm)

King Pin

50# or 90#

Landing gear

Single side operation or double side operation, Static capacity 28Ton

Accessory

One tooling box with a set of standard trailer tool

Electrical

Voltage

24V

Receptacle

7 ways (7 wire harness)

Lights

Front corner marker lamp :red ;reflector lamp :white

Side marker :orange

Rear lamp :red; rear reflector :white; turn single lamp :orange

Other

Usage

The height of the cargo's carrying platform is 800-1290mm, is suitable

 For the transportation of the large and non-dismantled objects.

Other Specifications

The max height of the rear guard from ground is 420mm

Other Descriptions

The whole body adopts steel with good quality, and be manufactured

by advanced skills and strict producing managerial processes. The

frame is wearing structure, webs made from manganese plates

from 400mm to 550mm high welded the upper and lower flange

plates together, and the beam runs through the longitudinal beam

makes the two parts a very strong unit by automatic submerged

arc welding. Frame using peen-forming processing.

Painting ,marking and side guard can according to the customer’s requirement




Packaging & Shipping

                       PACKAGING & SHIPPING

We transport the semi trailers by bulk or container. Our factory possesses long-term cooperation with ship agency which can provide you lowest shipping fee.



FAQ:lowbed series

                               MORE DETAILS

 Functions :

1. This series lowbed semi trailers are mainly used in heavy duty transportation for construction or logistic companies, such as excavators transportin ,digger, mover, crane, and building materials.
2. The capacity is for 30tons-500tons  , we can manufacture it according to your needs.
3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc
5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs



Detail process:

1. Send us inquiries on your desired product / mdel through our contact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.



Export Market Distribution:



Market

Total Revenue (%)

 Main Country

The Middle East

22.8

UAE,Bahrain,Iran,Iraq,Israel,Jordan,Kuwait,Lebanon,Oman Qatar,

Saudi Arabia,Syria,Yemen,Egypt

Southeast Asia

21.5

Vietnam, Philippines,Laos, Kampuchea, Thailand, Burma,

Malaysia, Singapore, Indonesia, Brunei, East Timor.

Central Asia

5.5

Kazakhstan, Uzbekistan, Kyrgyzstan, Turkmenistan, Tajikistan

Other Asia country

5.4

South Korea,India,Pakistan,Turkey

South America

8.8

Brazil, Bolivia, Uruguay, Peru, Chile, Argentina, Dominica, Cuba, Venezuela,Nicaragua,Guatemala,Ecuador,Bolivia

and so on.

Europe

7.8

Russia,Belarus and so on.

Africa

27.4

Congo, Tanzania, Ethiopia, Djibouti, Kenya, Angola, Chad,

Egypt, Sudan, Libya, Tunisia, Algeria, Sudan, Egypt, Libya,

 Eritrea, Uganda, Rwanda,Burundi and the Seychelles.

Mauritania, Western Sahara, Senegal, Gambia, Mali,

Burkina Faso, Guinea, Guinea-Bissau, Cape Verde,

Sierra Leone,Liberia, Côte d'Ivoire, Ghana, Togo, Benin,

 Niger, Nigeria and the Canary Islands. Cameroon, Equatorial

Guinea, Gabon and Zambia, Angola,Zimbabwe,

 Malawi, Mozambique, Botswana, Namibia, and so on.

North America

0.8

Canada ,America,Mexico





Your questions,we will anwser:



1. Can i have samples of this type of trailer to test the quality?



Yes, you can buy any samples to test the quality,our MOQ is 1 set.



2. What's the delivery time and can you lower the price?



It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.



3. Can i customize the painting and the trailer design?



Yes, we offer customized design and logo for reasonable type.



4. What's the payment method?



TT 30% as Deposit, Balance Before shipment by TT or L/C at sight

5.How do you ensure its quality?

We are direct factory and we have professional quality inspector.We will not let any imperfections departure from our factory.

6.Can you provide the certificate we need?

Yes,We can provide the certificate you need,such as FORM E,Certificate of origin,CNCA,SONCAP,ASME,DOT,ECE as so on.



Factory & Products

                        FACTORY & PRODUCTS

We are direct manufacturer and we have strong producing capacity and R&D capacity!Our raw material and OEM parts including axle, suspension, tyre, are purchased centralizedly by famous brand , every node will be inspected strickly. Moreover, advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding qulity.



After-sale Service

                         AFTER-SALE SERVICE

THE MAIN COMPONENTS OF THE WARRANTY PERIOD (SEE TABLE):

ITEM NAME

WARRANTY

ITEM NAME

WARRANTY

MAIN FRAME

 FRAME

1 YEAR

RUNNING GEAR

AXLE

6 MONTHS

SUSPENSION

6 MONTHS

AXLE BEARING

3 MONTHS

KING PIN

1 YEAR

WHEEL HUB

3 MONTHS

BALANCE ARM

3 MONTHS

TIRE

6 MONTHS

ITEM NAME

WARRANTY

ITEM NAME

WARRANTY

BRAKING DEVICE

BRAKE DRUM

3 MONTHS

SUPPORT DEVICE

LANDING GEAR

6 MONTHS

BRKE CHAMBER

3 MONTHS

SPARE WHEEL CARRIER

6 MONTHS

AIR RESERVOIR

6 MONTHS

ITEM NAME

WARRANTY

OTHERS

LEAF SPRING

3 MONTHS

BRAKE CHAMBER DIAPHRAGM

3 MONTHS

EMERGENCY RELAY VALVE

3 MONTHS

BRAKE SHOE

3 MONTHS

RELAY VALVE

3 MONTHS
